JONSBO CABINET FAN – FR-231 RGB (SET OF 3)

FR-231, one of the FR series, is designed by JONSBO team which is focus on light effect PC platform, striving to reflect the simple and elegant texture light effect. FR-231 uses magnesium aluminum material circular modeling and combining with large area flat-shaped apertures structural design, with strong game feeling hexagonal holes in the circular modeling ring. In order to have good light effect no matter where to be installed, FR-231 is also surrounded by hexagonal shaped light effects to show good side light effect. Design with using of aluminum magnesium alloy material not only enhances the structural strength of the fan, but also reflects the distinctive metal texture.
        The control module of FR-231 can achieve different functions, it can let the fan changing 256 colors automatically, lock any of the 256 colors, automatically change and lock the breathing light mode, switch among high speed, low speed and stop.

Specifications

Model:FR-231 Fan

Nomber of fan: 3 pcs

Dimension:120MM (W) * 120MM (D) * 25MM (H)

Rotation speed:   900rpm~1500rpm?10%

Air flow: 20.8CFM~38.6CFM (each)

Noise level:   18db.A~25.4 db.A

Voltage: 12V(FAN) / 5V(LED)

Total Power: 11.04W

Bearing: Hydraulic bearing

Connector: 1*6PIN ?SATA?

Weight: 650g
